Specifications
| Length | 12 - 45 mm |
| Material | Stainless |
| Thread Pitch | 0.7 mm |
| Fully Threaded | Fully Threaded |
| Head Diameter | 7.5 mm |
| Head Height | 2.2 mm |
| Countersink Angle | 90° |
| Drive Style | PH Philips |
| Drive Style | PH-2 |
| Thread Type | Metric |
| Thread Spacing | Coarse |
| Thread Fit | Class 6h |
| Thread Direction | Right Hand |
| Head Type | Flat |
| Flat Head Profile | Standard |
| System of Measurement | Metric |
| Specifications Met | DIN 965 |
| RoHS | RoHS (2015/863/EU) Compliant |
| REACH | REACH Compliant |
| Country of Origin | Türkiye |
| Thread Size | M4 |
| Material | 304 Cu. Paslanmaz (1.4567) |
| Surface Protection | passivation |
