Specifications
| Color | Light Gray |
| Material | ABS |
| Mounting Plate | with Mounting Plate, without Mounting Plate |
| Top Cover | Transparent Cover, Flat Cover |
| Type | Thickness 130 mm |
| E1 | 280 |
| E2 | 256 |
| E3 | 237 |
| E4 | 200 |
| B1 (mm) | 280 |
| B2 (mm) | 237 |
| B3 (mm) | 200 |
| D1 (mm) | 127 |
| D2 (mm) | 112 |
| D3 (mm) | 97 |
| D4 (mm) | 30 |
| P1 (mm) | 238 |
| P2 (mm) | 238 |
| Material | PC |
| A (mm) | 280 |
| B (mm) | 280 |
| C (mm) | 128 |
| Operating Temperature | -30° / +70° |
| IP Rate | IP67 |
| Units per box | 1 |
