Specifications
| Color | Light Gray |
| Mounting Plate | with Mounting Plate, without Mounting Plate |
| Top Cover | Transparent Cover, Flat Cover |
| E1 | 150 |
| E2 | 128 |
| E3 | 108 |
| E4 | 108 |
| B1 (mm) | 150 |
| B2 (mm) | 108 |
| B3 (mm) | 108 |
| D1 (mm) | 89 |
| D2 (mm) | 76 |
| D3 (mm) | 69 |
| D4 (mm) | 20 |
| P1 (mm) | 124 |
| P2 (mm) | 124 |
| Material | ABS, PC |
| A (mm) | 150 |
| B (mm) | 150 |
| C (mm) | 89 |
| Operating Temperature | -30° / +70° |
| IP Rate | IP67 |
| Units per box | 1 |
