Especificações
| Cor | Cinzento escuro |
| Material | ABS |
| Capa superior | Tampa transparente, Cobertura opaca |
| UL94 | HB |
| E1 | 158,5 |
| E2 | 113 |
| E3 | 81,5 |
| E4 | 138,5 |
| B1 (mm) | 80 |
| B2 (mm) | 73 |
| B3 (mm) | 60 |
| B4 (mm) | 50 |
| D1 (mm) | 59 |
| D2 (mm) | 43,5 |
| D3 (mm) | 43,5 |
| D4 (mm) | 15 |
| Material | ABS |
| A (mm) | 158.5 |
| B (mm) | 80 |
| C (mm) | 59 |
| Temperatura de funcionamento | -30° / +70° |
| Taxa IP | IP67 |
| Unidades por caixa | 10 |
