Технические характеристики
| Цвет | Темно-серый |
| Верхняя обложка | Прозрачная крышка, Плоская крышка |
| E1 | 237 |
| E2 | 188 |
| E3 | 160 |
| E4 | 215 |
| B1 (mm) | 82 |
| B2 (mm) | 73 |
| B3 (mm) | 45 |
| B4 (mm) | 50 |
| D1 (mm) | 70 |
| D2 (mm) | 55 |
| D3 (mm) | 50 |
| D4 (mm) | 20 |
| Материал | ABS, ПК |
| UL94 | HB |
| A (мм) | 236,8 |
| B (мм) | 81,7 |
| C (мм) | 69,75 |
| Рабочая температура | -30° / +70° |
| IP Rate | IP67 |
| Единицы в коробке | 5 |
